Excavators

YH16

YH16 is a 0.9 t mini excavator powered by a KOOP192F diesel engine. The published table lists a 3,100 mm digging radius, a rated power of 7.6 kW at 3,000 rpm and a 0.03 m³ bucket.

Operating Weight (kg)900
Rated Power (kW/rpm)7.6/3000
Bucket Capacity (m³)0.03
Max. Digging Depth (mm)1800

Request a quote Full specifications

Specifications

Figures as published in the YHONG product catalogue. Configurations vary by market; confirm the final specification on your quotation.

YH16 specifications
Engine Model	KOOP192F
Power Type	Single-cylinder/Four-stroke/Air-cooled/Vertical
Fuel Type	Diesel
Displacement (cc)	499
Rated Power (kW/rpm)	7.6/3000
Horsepower (HP)	10.3
Fuel Tank Capacity (L)	5.5
Overall Dimensions (mm)	2230/4160 × 1100 × 2200
Operating Weight (kg)	900
Bucket Capacity (m³)	0.03
Track Ground Contact Length (mm)	1000
Track Width (mm)	180
Max. Digging Depth (mm)	1800
Max. Dumping Height (mm)	1745
Max. Digging Height (mm)	2300
Max. Digging Radius (mm)	3100
Gradeability (°)	30
Travel Speed (km/h)	0-3
Bucket Digging Force (kN)	15

Where the YH16 works

It is suitable for mountain land reclamation, municipal engineering, landscaping, water and electricity installation, orchard ditch digging and weeding, rural sewer dredging, etc.

Landscaping and garden design
Utility and service trenching
Footing and foundation excavation
Drainage and French drain work
Pool and patio preparation
Rental fleet general hire
Interior and basement work
Demolition and site clearance

Optional equipment

Engine optional:Kubota D722, Koop 192 (Euro V), Changchai 192, Briggs&Stratton 25T2, RATO420 ; Optional configurations: driver's cab, large arm side swing, chassis extension and retraction.
